DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-11
2.1.5 Decathlon D80 Primary Components
ITEM PART # COMPONENT
* 823-3494SP
Frypot - S/S 1
1
⁄
4
" Drain (D80, after 10/99)
* 826-1891
Frypot - S/S 1
1
⁄
4
" Drain (D80, before 10/99)
* 823-3396SP
Frypot - S/S 1
1
⁄
2
" Drain (D80, SCFD80)
2 810-2072 Gas Manifold (welded assembly)
3 810-2049 Orifice, Natural Gas #43 2.26 mm (non-CE D80G)
* 810-0710 Orifice, LP Gas #54 1.40 mm (non-CE D80G)
* 810-2161 Orifice, Natural Gas #38 2.58 mm (non-CE D80GHP)
* 810-2063 Orifice, LP Gas #52 1.61 mm (SCFD80G)
* 810-2060 Orifice, G20/G25 Gas (CE only)
* 810-2059 Orifice, G31 (CE only)
4 810-2032 Pilot Burner, Natural/G20/25 Gas (primary and trailing)
* 810-2155 Pilot Burner, LP/G31 Gas (primary and trailing)
* 812-1674
Pilot Burner, Mod. Natural Gas (electronic ignition)
* 809-0845
Screw, 10-32 x
3
⁄
8
" Hex Slotted Head (primary and trailing)
* 812-1674
Tube, Pilot Gas Supply,
1
⁄
4
" x 23" (one-piece gasline)
* 810-0705
Tube, Pilot Gas Supply,
1
⁄
4
" x 20" (one-piece gasline)
* 810-0703
Tube, Pilot Gas Supply,
1
⁄
4
" x 17
3
⁄
4
" (one-piece gasline)
* 810-2138 Valve, Trailing Pilot, Adjustable (trailing pilot only)
5 200-1314 Manifold Support Bracket
* 200-1615 Manifold Support Bracket (right or left)
6 210-5197 Diffuser Assembly
7
►►► See Drain Manifold Components, Section 2.5
8 810-2151 Burner, Left Side
9 810-2149 Burner, Center
10 810-2150 Burner, Right Side
11 200-2707 Heat Shield
* 200-1363 Lower Heat Shield
12 807-3552 Gas Valve, Natural Gas Electronic Ignition, 24 VAC
* 807-3628 Gas Valve, LP Gas Electronic Ignition, 24 VAC
* 810-2156 Gas Valve, Natural Gas, 120 VAC
* 810-2323 Gas Valve, LP Gas, 120 VAC
* 807-2091 Gas Valve, G20/25 Gas, 24 VAC (CE only)
* 807-2127 Gas Valve, G31 Gas, 24 VAC (CE only)
* 810-0691 Vent Tube
13 200-2686 Channel, Front and Rear
14 200-1675 Lower Hinge Bracket
*
823-5346 Hinge, Lower Left
*
823-5347 Hinge, Lower Right
*
823-5348 Hinge, Upper Left
*
823-5349 Hinge, Upper Right
15 211-2532 Side Panel, Left Side (D80)
16 212-2532 Side Panel, Right Side (D80)
* 201-4775 Side Panel, Left Side with hole (SCFD80)
* 202-4775 Side Panel, Right Side with hole (SCFD80)
* 211-4570 Side Panel, Left Side without hole (SCFD80)
* 212-4570 Side Panel, Right Side without hole (SCFD80)
17 824-0954 Wireway, Control Panel
18 210-2778 Control Panel, One Hole (D80)
* Not illustrated.
