DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-12
2.1.5 Decathlon D80 Primary Components (cont.)
ITEM PART # COMPONENT
* 210-2777 Control Panel, Two Holes (D80)
* 210-5061 Control Panel, One Hole (SCFD80)
* 210-5910 Control Panel, Two Holes (SCFD80)
19
►►► See Optional Components, Section 2.3
20 824-0986 Top Cap (D80/CFD80)
* 824-1013 Top Cap, 2-battery (SCFD80)
* 824-1007 Top Cap, 3-battery (SCFD80)
* 824-1006 Top Cap, 4-battery (SCFD80)
21 823-3659 Flue Box Assembly (D280, SCFD280)
* 106-1442SP Flue Box Assembly (D380/480, CFD80, SCFD380/480)
* 200-1347 Front, Flue Box
* 200-1349 Back, Flue Box
* 200-1316 Shield, Flue Box
* 200-3645 Deflector, Flue
22 823-3512 Flue Cap (D80)
* 823-3659 Flue Cap (SCFD80)
23 106-1698SP Door Assembly
* 210-1151 Panel, Outer Door
* 200-2688 Panel, Inner Door
* 810-0180 Door Handle, Chrome
* 809-0918 Screw, 10-24 x
1
⁄
2
" Slotted Head (use with 810-2105)
* 809-0191 Washer,
1
⁄
4
" Spring-lock (use with 810-2105)
* 200-1301 Pin, Door, Long (D80)
* 210-9889 Pin, Door (SCFD80)
* 810-0066 Magnetic Catch, Door (D80)
* 810-1105 Magnetic Catch, Door (SCFD80)
24 803-0304 Fry Basket, 6 x 8
3
⁄
4
" x 16
3
⁄
4
"
25 810-2122 Grid Assembly (mesh-style)
* 803-0300 Grid Assembly (rack-style)
26 200-3120 Hanger, Basket, Single System, M/S (D80)
* 210-2887 Hanger, Basket, Single System, S/S, no splash guard (SCFD80)
* 200-3119 Hanger, Basket, Double System, M/S (D80)
* 210-3117 Hanger, Basket, Double System, S/S (SCFD80)
27 810-0356 Caster, Plate-mount, 5-inch without Brake
* 810-2406 Caster, Single Stud-mount, 5-inch without Brake
28 810-0357 Caster, Plate-mount, 5-inch with Brake
* 810-2405 Caster, Single Stud-mount, 5-inch with Brake
* 826-1389 Screw,
1
⁄
4
-20 x
3
⁄
4
" Hex Head (for plate-mount casters, qty: 10)
29 812-1226SP Drain Nipple, Extended, 1 ¼”
* 812-1717SP Drain Nipple, Extended, 1 ½”
30 106-0913SP Cordset, 10’ Power
31 210-2804 Cover, Outlet Duct
32 200-2683 Back, Upper Cabinet
* 200-2982 Back, Lower Cabinet
33 810-2411 Leg, Single Bolt Mount (black)
* 806-3811 Leg Package, 4 Bolt Mount (4 per set)
34 823-3248 Leg Support Assembly
35 200-2734 Burner Mounting Bracket
36 823-3649 Hanger, Basket with 6” Splash Guard
* Not illustrated.
