DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-35
2.9 SUFF Filtration Components
2.9.1 SUFF Filtration Components; D50 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1 823-3796 Filter Pan (SUFF 50)
* 813-0684 Plug, Hex Socket, 3/8" NPT
* 813-0679 Plug, 1/8" SS Square Head (Female Disconnect)
2 823-3790 Support Grid, Bottom Pan Screen
3 803-0317 Filter Paper, 8-1/4 x 25-3/4"
4 823-3795 Hold-down Ring, Weighted
5 823-3736 Crumb Basket
6 823-3797 Filter Pan Cover, Front
7 823-3798 Filter Pan Cover, Back
8 809-0428 Screw, ¼-20 x ½" Steel
9 823-4794 Insert, Caster
10 809-0820 Nut, Oval Locking, ¼-20
11 809-0805 Screw, ¼-20 x ½"
12 810-2805 Caster, 2"
* Not Illustrated.
