General
The FMS3000 consists of several modules in separate housings. The individual modules are
connected to each other through an internal BUS (Binary Unit System) and a common supply voltage
(24V DC). All modules, with the exception of the main panel, are intended for mounting on a support
rail and are normally installed together in a metal switch cabinet. The main panel (HT) is constructed
as a front panel built-in device. The FMS3000 can either be wall mounted or mounted in a console.
When a fire detector detects a fire, then the fire loop module (FM) recognises the event. The main
module (BUS Master) cyclically queries the status of all modules. In the course of this, it receives the
fire alarm from the fire loop module (FM). Independent of the configuration, the main module transmits
to the output module which outputs it should connect. In addition, it transmits the fire alarm to the
VDR module and printer module (if present). VDR and printer module output the fire alarm through a
VDR output or through the printer. In addition, the main module informs the main panel (HT) about the
fire alarm, and it then warns the user acoustically and optically of a fire.
1. Cabling requirements
For safe operation of the entire system, the following cables are recommended:
Plug
Modul
e
Cable type
Wires
-
diameter
POWER Main (JN0-M) power supply unshielded cable Min. 3 x 1.5mm²
POWER Emergency
(JN0-E)
power supply unshielded cable Min. 3 x 1.5mm²
24V OUT (JN1) power supply unshielded cable Min. 2 x 1.5mm²
24V IN/AKKU (JN1) main module unshielded cable Min. 2 x 1.5mm²
(power supply); Min 2
x 1.5mm²
(accumulator)
MONITORING (JN2) power supply/main
module
unshielded cable Min. 6 x 0.75mm²
RELAY (JP10) main module unshielded cable Min. 2x0.75mm²
FMS-BUS (JP1-JP9) main module/fire loop
module (FM)/output
module/VDR
module/printer module
shielded twisted pair
cable
2x2x0.75mm²
RELAY (JAN,JAP) fire loop module (FM) unshielded cable Min. 2-5 x 0.75mm²
1
2
LOOP (JLN, JLP) fire loop module (FM) unshielded cable Min. 2-8 x 0.75mm²
3
4
RELAY (JR1, JR2) output module unshielded cable Min. 2/8 x 0.75mm²
24V OUT (JOC1) output module unshielded cable Min. 2/4 x 0.75mm²
TST IN+24V OUT
(JOC2)
output module unshielded cable Min. 2/4 x 0.75mm²
FMS-BUS (JR1) main panel shielded twisted pair
cable
5 x 2 x 0.75mm²
