3. Pull the hook connecting the Mixing Chamber Cover (1) to the Mixing Cham-
ber (3) and left the edge of the cover to remove.
4. Gently remove the Extrusion Pipe (4) by pulling it directly forward and out of
the front opening of the Mixing Chamber (3).
5. Remove the Mixing Paddle (2) by pulling it upward from the motor shaft locat-
ed at the top of the Mixing Chamber (3).
6. Remove the Mixing Chamber (3) by pulling it forward from the Base (9).
8
