Wiring
Confirm that the voltage to be
applied to the unit is within
±10% of the rated voltage
stated on the unit nameplate
and to the other requirements
of Installation - Wiring -
Power.
For units with air-cooled air
conditioning, confirm that the
voltage applied to the remote
condenser corresponds to that
specified on the condenser
nameplate.
Confirm that the size of the
wire supplying electric power
to the DRY-O-TRON
® is ade-
quate for the circuit ampacity
shown on the nameplate.
For long lengths of power
wiring or marginal voltage,
confirm that the wire size is
adequate for less than 10%
voltage drop under
compressor starting current.
Confirm that only copper wire
was used for any connections
to the DRY-O-TRON®.
Confirm that the unit is
properly grounded.
Confirm that all electrical con-
nections have been checked
for tightness and re-torqued as
necessary.
Confirm that all electrical
enclosures are clean and dry.
For 3-phase units, confirm that
the phase sequence is correct
for proper blower rotation.
See Setup - Airflow.
Confirm that all conduits
entering units have been
sealed. See Installation -
Wiring - Power and
Installation - Wiring -
Control Signals.
For units with optional remote
controller displays, confirm
that the remote displays are
wired per the recommenda-
tions in this manual. See
Installation - Wiring - Control
Signals - Optional Remote
Display.
Confirm that all control signals
are wired per published
standards and the recommen-
dations in this manual. See
Installation - Wiring - Control
Signals.
Confirm that any special wiring
has been accomplished per
the instructions in any
applicable appendix. See
Installation - Wiring -
Special.
Ducts
For end-return units, confirm
that the the return duct has the
minimum straight length (see
Installation - Unit-Duct
Connections).
Confirm that the supply duct
has the minimum straight
length (see Installation - Unit-
Duct Connections).
For units with outdoor air
intakes, confirm that the intake
duct is properly connected
(see Installation - Air
Distribution - Ventilation).
For units with an outdoor air
intake, confirm that the intake
hood is unobstructed.
Confirm that outdoor air will be
heated as necessary to assure
that all outdoor air entering the
unit will be above 32°F (0°C).
See Installation - Minimum
Outdoor-Air Temperature.
Confirm that the ventilation-
duct procedures specified in
this manual and in the appro-
priate appendices have been
applied. See Installation -
Ducts - Ventilation.
Confirm that the outdoor air
intake duct (if any) is not
brought into the unit’s return
duct. See Installation - Air
Distribution - Ventilation.
For units with duct-mounted
heaters, confirm that the
heater is no closer than 5
times the width of the duct to
the DRY-O-TRON®.
Dectron, Inc. March 2012
DSH/DSV/RSH/DBH/RBH Series Dehumidifier Owner’s Manual
Startup Pre-Startup Checklist
Data subject to change without notice.
216
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
your
initials
Date: ________________
Model No. ________________
Serial No. ________________
Ref. No. _________________
Name _________________
Tel. _________________
STARTUP
6.10
