DECTRON
The maximum amount of outdoor air that can enter a unit depends on the outdoor temperature
and the unit options.
••
The air-handler nameplate shows the required supply airflow rate in cubic feet
per minute (CFM) at sea level, marked “AIR VOLUME”.
••
Where connected to the DRY-O-TRON
®
, the outdoor-air intake (if any) flow rate
is determined by the project engineer. Any outdoor airflow rate must not exceed
the value
shown in the chart below, except:
a) Units with the Economizer option can have up to 100% of nameplate value AIR VOLUME
during Economizer mode.
b) Units with the Intelligent Energy Saver option can have up to 100% of nameplate value
AIR VOLUME during Intelligent Energy Saver mode.
c) Units with the Purge option can have up to 100% of nameplate value AIR VOLUME during
Purge mode.
d) Units specially designed and documented for different conditions.
Dectron, Inc. March 2012
Owner’s Manual
DSH/DSV/RSH/DBH/RBH Series Dehumidifier
Outdoor-Air Intake Building Construction
Data subject to change without notice.
33
NOTICE
Risk of unit damage. Risk of building damage from water leakage.
Apply the requirements applicable to your unit. Do not confuse options.
DRY-O-TRON ®
MODEL #:
SERIAL #:
I.D.
D
ELECTRICAL RATING
460 V ac, 3 ph, 60 Hz
COMPRESSOR
LRA RLA
COMPRESSOR
LRA RLA
COMPRESSOR
LRA RLA
COMPRESSOR
LRA RLA
BLOWER MOTOR HP FLA
BLOWER MOTOR HP FLA
BLOWER MOTOR HP FLA
COND. FAN MOTOR HP FLA
COND. FAN MOTOR HP FLA
PUMP MOTOR HP FLA
ENTHALPY MOTOR HP FLA
ELECTRIC HEATER kW A
Max. L.A.T . (°F)
SERVICE POWER
SPACE HEATING COIL
PSIG Max.
MCA A MAX. FUSE/CKT. BKR.*
15
A
*(HACR type per NEC)
R-22 FACTORY CHARGE
lbs
AIR VOLUME CFM
BELT SIZE
WIRING DIAGRAM
REFRIGERANT DESIGN PRESSURES: HIGH/LOW 300/150 PSIG
FABRIQUÉ AU CANADA / MADE IN CANADA
REF.:
POOL # 1: ft² POOL # 3: ft²
E.W.T.: °F E.W.T.: °F
POOL # 2: ft² POOL # 4: ft²
E.W.T.: °F E.W.T.: °F
AIR TEMP.: °F R.H.: %
R-22 TOTAL SYSTEM CHARGE:
lbs
MAX. LENGTH OF REF. LINES (ONE WAY) ft
BETWEEN D.O.T. & REMOTE CONDENSER:
LINE SIZE:
AIR COOLED COND. MODEL #:
HOT GAS: in
LIQUID: in
BUILDING
CONSTRUCTION
32°F
0°C
0°F
-18°C
-20°F
-29°C
5%
35%
30%
25%
20%
15%
10%
5%
35%
30%
25%
20%
15%
10%
50°F
10°C
100°F
38°C
91°F
32°C
150°F
66°C
allowable outdoor-air
intake rates for units
without
air-conditioning option
allowable outdoor-air
intake rates for units
with A/C option
(includes area below)
allowable outdoor-air
intake rates for units
with A/C option and
either O/A preheat or
the SmartSaver option
(includes area below)
allowable outdoor-air
intake rates for units
without A/C option but
with either O/A preheat
or with the
SmartSaver option
Allowable flowrate of outdoor air entering a unit, as a percentage of AIR VOLUME
Intake-Air
Temperature
38°F
3°C
2.17
