After Sales level - #PARAMETERS Menu
Parameter Description
PERMUT
Master boiler active
STAGE
Number of boilers requesting heating
NB.CASC.
Number of boilers recognised in the cascade
NB. VM:
Number of DIEMATIC VM control systems recognised in the cascade
POWER %
Current output of the boiler
SPEED FAN
(1)
Fan rotation speed
SETPOINT FAN
Fan rotation speed desired
MEAN OUTSIDE T
Average outside temperature
CALC.T.BOILER
Temperature calculated by the boiler
BURNER SETPOINT
Set point parameter of the burner
MEAN BOILER T
Average temperature of the boiler flow sensor
BOILER TEMP
(1)
Measurement of the boiler flow sensor
BACK TEMP
(1)
Temperature of the boiler return water
TEMP.SYSTEM
(1)
Temperature of the system flow water if multi-generator
CALC T SYST
(2)
System flow temperature calculated by the control system
CALCULATED T.A
Calculated temperature for circuit A
CALCULATED T. B
(3)
Calculated temperature for circuit B
CALCULATED T. C
(3)
Calculated temperature for circuit C
OUTLET TEMP.B
(1)
(3)
Temperature of the flow water in circuit B
SWIMMING P.T.B
Temperature of the swimming pool water sensor on circuit B
OUTLET TEMP.C
(1)
(3)
Temperature of the flow water in circuit C
SWIMMING P.T.C
Temperature of the swimming pool water sensor on circuit C
OUTSIDE TEMP.
(1)
Outside temperature
ROOMTEMP.A
(1)
Room temperature of circuit A
ROOMTEMP.B
(1)
(3)
Room temperature of circuit B
ROOMTEMP.C
(1)
(3)
Room temperature of circuit C
DHW TEMP.
(1)(3)
Water temperature in the DHW tank
TEMP.EXCHANGE
Exchanger temperature
IN 0-10V
(1)(3)
Voltage at input 0-10 V
CURRENT
(1)
Ionization current
PRESSURE
(1)
Water pressure in the installation
STOR.TANK.TEMP
(1)
(3)
Water temperature in the storage tank
T.DHW BOTTOM
(1)(3)
Water temperature in the bottom of the DHW tank
DHW A TEMP.
(1)(3)
Water temperature in the second DHW tank connected to circuit A
TEMP.TANK AUX
(1)(3)
Water temperature in the second DHW tank connected to the AUX circuit
KNOB A
Position of temperature setting button on room sensor A
KNOB B
(3)
Position of temperature setting button on room sensor B
KNOB C
(3)
Position of temperature setting button on room sensor C
OFFSET ADAP A
Parallel trigger calculated for circuit A
OFFSET ADAP B
(3)
Parallel trigger calculated for circuit B
OFFSET ADAP C
(3)
Parallel trigger calculated for circuit C
(1) The parameter can be displayed by pressing key f.
(2) The parameter is only displayed if CASCADECADE} is set to ON
(3) The parameter is only displayed for the options, circuits or sensors actually connected
