DeDietrich Diematic iSystem User Manual

After Sales level - #TEST OUTPUTS Menu
Parameter Adjustment range Description
P.CIRC.A ON / NO
Stop/start pump circuit A
P.CIRC.B
(1)
ON / NO
Stop/start pump circuit B
P.CIRC.C
(1)
ON / NO
Stop/start pump circuit C
HW.PUMP
(1)
ON / NO
Stop/start domestic hot water pump
AUX.CIRC. ON / NO
On/Off auxiliary outlet
3WV B
(1)
REST
No command
Open
Opening 3-way valve circuit B
CLOSE
Closure 3-way valve circuit B
3WV C
(1)
REST
No command
Open
Opening 3-way valve circuit C
CLOSE
Closure 3-way valve circuit C
TEL.OUTPUT ON / NO
On/Off telephone relay outlet
(1) The parameter is only displayed for the options, circuits or sensors actually connected
After Sales level - #TEST INPUTS Menu
Parameter Status Description
PHONE REM.
Bridge on telephone input (1 = presence, 0 = absence)
FLAME
Flame presence test (1 = presence, 0 = absence)
GAS VALVE
OPEN/CLOSE Opening the valve
Closing the valve
FAILURE ON
Fault display
OFF
No fault
SEQUENCE
Control system sequence. ¼See chapter: "Control system sequence", page 83
HOT
Index of the generator in the system
TYPE
Generator type
R.CTRL A
(1)
ON
Presence of a remote control A
OFF
No remote control A
R.CTRL B
(1)
ON
Presence of a remote control B
OFF
No remote control B
R.CTRL C
(1)
ON
Presence of a remote control C
OFF
No remote control C
After Sales level - #INFORMATION menu
Parameter Description
S/N SCU
Serial number of the SCU board
CTRL
Software version of the SCU board
S/N PCU
Serial number of the PCU board
VER.ROM PCU
Version of the PCU PCB programme
VERS.PARAM PCU
Version of the PCU PCB parameters
S/N SU
Serial number of the SU board
VERS.PARAM SU
Version of the SU PCB programme
VERS.PARAM PCU
Version of the SU PCB parameters
MC.VERSION
(1)
Version of the boiler radio module programme
VERS.SUN
(1)
Solar control system software version
(1) The parameter is only displayed for the options, circuits or sensors actually connected
(2) The parameter is only displayed if INSTALLATION is set to EXTENDED
Diematic iSystem For C 330 / C 630 ECO 7. Troubleshooting
31082018 - 7600691-001-06
82
