DeDietrich EASYMATIC Instructions For Use, Electrical Connection, Start Up

3/3
E control panel
CONTROL PANEL
1 8578-7001 Complete Easymatic co
ntrol panel
2 8578-8506 Complete Easymatic card
cover
3 9786-4039 Easymatic front panel
4 9532-5027 Green On/Off two-pole switch
5 8500-0035 Two-pole switch
6 9532-5028 Moment inverter two pole switch
7 8500-0032 110°C safety thermostat
8 8500-0002 30-90 °C setting thermostat
9 9752-5181 Setting button
10 9534-0288 Circuit breaker 4A TS710/4A
11 9536-5147 Flat thermometer
12 9521-6220 Red light
13 8806-7511 Easymatic module CDC 2
14 9655-0352 WSBH-2 harness fastening
15 8575-8019 Board supports
16 8578-4905 Diematic Easy Standard harness
17 8578-4906 Burner cable
18 8806-5565 Easymatic relay board
19 8575-4905 3-pin connector power supply
20 8575-4922 4-pin connector power supply VA+CS
21 8575-4924 Pump 3-pin connector A/VS
22 8575-4918 2-pin connector boiler sensor
23 8575-4911 EPT2-pin connector room sensor
24 8575-4928 EPT connector RT
25 8575-5520 Control panel screw bag
26 9655-0357 8-pin flat cable L = 300
27 8575-4918 KVT 60 sensor - lenth 1 m
EXTERNAL SENSOR
950 8575-7741 External sensor (Package FM46)
951 9536-2450 External sensor AF60
952 8575-4906 2-pin external sensor connector
DHW SENSOR OPTION (PACKAGE FM 45)
990 8575-7740 D.h.w. sensor (Package FM 45)
991 8575-4935 Installed d.h.w. sensor
992 8575-4909 D.h.w. sensor 2-pin connector
993 9536-2448 KVT 60 sensor L = 5M
994 8575-4925 2-pin external connector d.h.w. sensor
995 9536-5613 Contact spring for thimble tube
Mark. Code No. DESCRIPTION Mark. Code No. DESCRIPTION
10/09/03
