Wall-mounted indoor units (UME)
Dimensions of wall-mounted indoor units:
Width (mm)
Height (mm)
Depth (mm)
UME20
800
300
198
UME25
800
300
198
UME35
800
300
198
UME50
970
314
235
Ensure that you respect the following requirements for installation:
Installation of the wall-mounted indoor unit:
Width
Height
Distance from the ceiling
Distance from
the wall
Distance from the floor
Distance from
the wall
