20181270 CR v8-2019Page 36
Ensure that the installation configuration is able to withstand four times the weight of the indoor unit. It must not
increase the noise level or vibrations.
Installation of the indoor unit and grille:
The grille comprises four clips which are fixed onto the appliance's support. The grille must be positioned using
these components.
The grille is then secured in place using four bolts which are accessed via the grille's four corner panels.
The four connecting bolts are located inside the grille's access panel.
Distance between 2 indoor units > 4000
