DeDietrich S3 - Connecting the Flue Gas Thermometer (Package BP28)

12
Control panel S3 23/01/06 - 300008905-001-A
7 Connecting the flue gas thermometer (Package BP28)
An optional flue gas thermometer may be fitted on the front of the
control panel.
To do so:
- Cut the cover off with a cutter along the edges of the coloured
rectangle
- Clip the thermometer into the opening
- Bring the sensor to the back of the boiler via the cable channel and
insert it in the flue gas pipe.
M000493
