23/01/06 - 300008905-001-A Control panel S3
Rep Code no. Description
1 100004299 Standard complete control panel
2 8219-0508 Painted control panel base
3 8557-0505 Cover
4 300007160 Side plate
5 200005221 Plastic coated panel
6 9532-5027 Green S/S bipolar switch
7 9536-5161 Thermometer
8 9532-5092 Bipolar switch
9 9536-3314 110 °C safety thermostat
10 9536-3364 30 to 90 °C setting thermostat
11 8555-5501 Setting button + Pin
12 9534-0286 Timed circuit breaker (10 A)
13 200005244 Standard beam
14 8219-4905 Electric circuit
15 9531-7395 7-pin plug
16 9531-7384 4-pin plug
17 9536-5613 Contact spring for pocket
18 9758-1286 Spring for pocket
