DEEP SEA ELECTRONICS DSECONTROL DSE7000 Series User Manual

DSE Model 7000 Series Control and Instrumentation System Operators Manual
78 Part No. 057-074 7000 Series OPERATING MANUAL ISSUE 2 02/05/2008 ADM
NEMA CLASSIFICATIONS
7000 series NEMA Rating (Approximate)
12 (Front of module when module is installed into the control panel with the optional sealing gasket).
2 (front of module when module is installed into the control panel WITHOUT being sealed to the panel)
NOTE: - There is no direct equivalence between IP / NEMA ratings. IP figures shown are approximate
only.
1
IP30
Provides a degree of protection against contact with the enclosure equipment and against a limited amount of falling dirt.
2
IP31
Provides a degree of protection against limited amounts of falling water and dirt.
3
IP64
Provides a degree of protection against windblown dust, rain and sleet; undamaged by the formation of ice on the enclosure.
3R
IP32
Provides a degree of protection against rain and sleet:; undamaged by the formation of ice on the enclosure.
4 (X)
IP66
Provides a degree of protection against splashing water, windblown dust and rain, hose directed water; undamaged by the
formation of ice on the enclosure. (Resist corrosion).
12/12K
IP65
Provides a degree of protection against dust, falling dirt and dripping non corrosive liquids.
13
IP65
Provides a degree of protection against dust and spraying of water, oil and non corrosive coolants.

DEEP SEA ELECTRONICS DSECONTROL DSE7000 Series Specifications

General

Brand	DEEP SEA ELECTRONICS
Model	DSECONTROL DSE7000 Series
Category	Control Unit
Language	English
