5.4.1 INSTRUMENT PAGE CONTENT
Engine
• Engine Speed
• Oil Pressure
• Coolant Temperature
• Engine Battery Volts
• Run Time
• Oil Temperature*
• Coolant Pressure*
• Inlet Temperature*
• Exhaust Temperature*
• Fuel Temperature*
• Turbo Pressure
• Fuel Pressure*
• Fuel Consumption*
• Fuel Used*
• Fuel Level*
• Auxiliary Sensors (If fitted and configured)
• Engine Maintenance Due (If configured)
• Engine ECU Link*
*When connected to suitably configured and compatible engine ECU. For details of supported engines see
‘Electronic Engines and DSE wiring’ (DSE Part number 057-004)
Generator
• Generator Voltage (ph-N)
• Generator Voltage (ph-ph)
• Generator Frequency
• Generator Current
• Generator Earth Current
• Generator Load (kW)
• Generator Load (kVA)
• Generator Power Factor
• Generator Load (kVAr)
• Generator Load (kWh, kVAh, kVArh)
• Generator Phase Sequence
Mains (DSE7220/DSE7320 only)
• Mains Voltage (ph-N)
• Mains Voltage (ph-ph)
• Mains Frequency
About
• Module Type
• Application Version
• USB ID – unique identifier for PC USB connection
• Analogue Measurements Version
• Firmware Update Bootloader Version
