-11-
8.2 Propellers
A B
B A
HEAD
Connect each propeller to its corresponding motor shaft, either position
“A/B,” and lock the propeller to the motor shaft with a screw.
Attention: Pay attention to the “A” or “B” printed on each
propeller. The drone will not fly unless the correct propeller is
installed on the correct motor shaft.
8.3 Propeller Guard
As shown above, install the propeller guard to the motor base. Ensure
that the propeller guard is clamped to the motor base to avoid
unnecessary loss and damage during flight.
