defa.com 12
VAROITUS Tällä merkillä merkityissä kohdissa on kyseessä muu vaara, joka voi vahingoittaa itse tuotetta tai
muita sähkölaitteita. Tällä merkillä merkityt toimenpiteet tulee suorittaa erityisen huolellisesti.
WARNUNG Mit diesem Symbol gekennzeichnete Abschnitte weisen auf zusätzliche Gefahren hin, die zu
Schäden am Produkt selbst oder an anderen elektrischen Geräten führen können. Mit diesem Symbol
gekennzeichnete Handlungen sind mit besonderer Sorgfalt auszuführen.
WARNING Les sections portant ce symbole attirent l'attention sur les dangers supplémentaires susceptibles
d’entraîner des dommages pour le produit lui-même ou d'autres appareils électriques. Les actions portant ce
symbole doivent être effectuées avec un soin particulier.
ADVERTENCIA Las secciones marcadas con este símbolo avisan sobre peligros adicionales que pueden
provocar daños en el propio producto o en otros dispositivos eléctricos. Las acciones marcadas con este
símbolo deben realizarse con especial cuidado.
i
NOTICE Sections marked with this symbol draw attention to additional important information
and special features that are necessary for the reliable operation of the device. Actions marked
with this symbol should be carried out as required.
MERKNAD Avsnitt merket med dette symbolet gjør oppmerksom på viktig tilleggsinformasjon og
spesialfunksjoner som er nødvendige for pålitelig drift av enheten. Handlinger merket med dette symbolet må
utføres etter behov.
OBS Avsnitt markerade med denna symbol uppmärksammar ytterligare viktig information och
specialfunktioner som är nödvändiga för att enheten ska fungera tillförlitligt. Åtgärder markerade med denna
symbol bör utföras vid behov.
BEMÆRKNING Afsnit markeret med dette symbol gør opmærksom på yderligere vigtige oplysninger og særlige
funktioner, der er nødvendige for en pålidelig drift af enheden. Installationer markeret med dette symbol skal
ske som foreskrevet.
HUOMAUTUS Tällä merkillä merkityissä ohjeen kohdissa kerrotaan erikoisominaisuuksista ja annetaan tärkeitä
lisätietoja, joilla varmistetaan laitteen luotettava toiminta. Tällä merkillä merkityt toimenpiteet tulee suorittaa
tarvittaessa.
HINWEIS Mit diesem Symbol gekennzeichnete Abschnitte weisen auf weitere wichtige Informationen und
Besonderheiten hin, die für den sicheren Gerätebetrieb notwendig sind. Mit diesem Symbol gekennzeichnete
Handlungen müssen nach Bedarf ausgeführt werden.
NOTIFICATION Les actions portant ce symbole attirent l'attention sur des informations importantes
supplémentaires et des caractéristiques spécifiques nécessaires au fonctionnement fiable de l’appareil. Les
actions portant ce symbole doivent être effectuées tel que demandé.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DEFA Balancer and is the answer not in the manual?

DEFA Balancer Specifications

General IconGeneral
Product nameDEFA Balancer
Product or component typeCurrent sensor
Product specific applicationLoad monitoring
Product destinationSwitchboard
Tightening torque0.5Nm
SafetyIEC 61010-1
Maximum current [Imax][dependent on current sensor]
Starting current[min. load current possible to measure]
Supply voltage100-240 V AC, +/-10%
Power consumption0.03 A
Maximum input voltage0.333 VRMS AC
Type of measurementCurrent
Accuracy+/- 2%
Metering typeCurrent L1, L2 and L3
Range compabilityDEFA Power
Frequency50/60 Hz
Transmission mediumRadio frequency 2.4 GHz or 5 GHz (Wi-Fi), Ethernet
Radio/EMC2014/53/EU - RED
Antenna connectorSMA female
Cable entry0.2-2.5 mm2 / (AWG18 - AWG14)
Mounting modeDIN rail
Number of modular spacings2
Operating altitude (m.a.s.l)0.2000 m
Ambient air operating temperature-25°C to +60°C
Ambient air storing temperature-30°C to +70°C
