H Strike Plate 1
I Dust Box 1
J Key 2
K Drive-in Collar (Optional) 1
L Exterior Gasket 1
(/fullviews/1749761/1749761_files/1749761-21.png)
The bulged part of the mounting plate must face towards the door.
Slide the cable through the notch in mounting plate
Connect the cable firmly into connector port .
Note : The metal connector side should face outward.
(/fullviews/1749761/1749761_files/1749761-22.jpg)
Install batteries
(/fullviews/1749761/1749761_files/1749761-23.png)
(/fullviews/1749761/1749761_files/1749761-24.jpg)
Install battery cover
