2.Please set up the lock and perform bolt direction determination to complete the installation.
Enter default programming code (123456) and the lock will set up bolt direction to complete
installation.
Part Description
AA
2-5/16" (58 mm) Mounting Bolt
1-13/16" (46 mm) Mounting Bolt
2
BB 13/16" (20 mm) Screw 2
CC 3/4" (19 mm) Wood Screw 4
(/fullviews/1749761/1749761_files/1749761-19.png)
The latch bolt should be in retracted position.
(/fullviews/1749761/1749761_files/1749761-20.png)
Part Description Quantity
A Exterior Assembly 1
B Power Cable 1
C Torque blade 1
D Mounting Plate 1
E Interior Assembly 1
F Battery Cover 1
G Latch 1
OR
