Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware shown to actual size.
Part Description Quantity
AA Anchor 2
BB Mounting bracket screw 2
PACKAGE CONTENTS
AA BB
A
B
C
Installation
1
Determining the mounting
location
NOTE:
mounted higher than recommended, aiming the sensor
down will reduce the coverage area.
□ Determine the mounting location – wall or eave
mount.
□ Position the lamp heads (A) in the general
direction of the desired light coverage.
Wall Mount
Eave Mount
A
Part Description Quantity
A Lamp head
Motion sensor
1
B 1
C Mounting base 1
To Next Page
