Page 12
The upper basket may be lowered to facilitate the loading of larger items. The
adjustment method varies from model to model and you should check which method is
pertinent to your machine.
1
Release the latches on both the right and left tracks by opening them sideways.
Roll the basket forwards to remove it.
Reposition the basket so that the upper set of rollers engage in the tracks and close the
latches.
2
The basket , even fully loaded, may be adjusted without removing it from the machine.
The “elevator system’ at either side has a blue retainer. Grab one of the upper basket wires,
(left or right) and lift up (A). Repeat on other side. To lower the basket, press the latch on the
basket adjustment mechanism. (B)
3
Upper basket adjustment
10
(Depends
on model)
(Depends on model)
