PAGE 11 OF 22
COUNTERTOP INSTALLATION
Remove all packing material and accessories.
Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
Installation
1.Select a level surface that provides enough open space for the intake and/or outlet vents.
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be placed against a wall.
Leave a minimum clearance of 30cm above the oven, a minimum clearance of 20cm is required
between the oven and any adjacent walls.
(3) Do not remove the feet from the bottom of the oven.
(4) Blocking the intake and / or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
Plug your oven into a standard household outlet.
Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label.
WARNING:
Do not install oven over a range cooktop or other heat-producing appliance. If installed near
or over a heat source, the oven could be damaged and the warranty would be void.
WARNING:
Accessible surfaces may become hot during operation.

Defy DMO390 Specifications

General

Door hinge	Left
Control type	Touch
Display type	LCD
Door opening	Side opening
Product type	Solo microwave
Door material	Glass
Product color	Silver
Door open type	Button
Microwave power	900 W
Built-in display	Yes
Appliance placement	Countertop
Delayed start timer	-
Connected load	1400 W
AC input voltage	230 V
AC input frequency	50 Hz
Warranty period	2 year(s)

Weight and Dimensions

Depth	395 mm
Width	539 mm
Height	300 mm
Weight	15500 g
