Connecting the water drain hose for
models with the water tank at the bottom;
Connection pipe to water drain is at the
bottom rear of your machine.
1.Removethebracketandtherubbercap.
2. Attach the drain hose and replace the
bracket to its position.
Important:
C There is no pump in the machine, so ensure
that the hose is placed to allow a easy
water flow.
C The end of the hose should never be higher
than the level of the water outlet on the
machine.Otherwise,the“tankfull”LEDof
your machine will illuminate and stop the
program.
C If the dryer is mounted on the washing
machine by means of a bracket, use of
the water drain hose is recommended.
The drain hose should be directed
downwards as shown in the figure.
Electrical connection
Connect the machine to an earthed outlet
protected by a fuse of suitable capacity.
Important:
•Connectionshouldcomplywithnational
regulations.
•Powercordplugmustbewithineasyreach
after installation.
•Thevoltageandtheallowedfuseprotection
are specified in the section “Technical
Specifications”.
•Thestatedvoltagemustmatchwithyour
mains voltage.
•Connectionviaextensioncordsormulti-
plugs should not be made.
•Themainfuseandswitchesmusthavea
contact distance of minimum 3 mm.
B A damaged power cable must be replaced
by a qualified electrician.
B The appliance must not be operated unless
it is repaired! There is the risk of electric
shock!
Destroying packaging material
Packagingmaterialcanbedangerousto
children.Keepthepackagingmaterialsout
of the reach of children or dispose of them
accordingly. Do not dispose of them together
with normal domestic waste.
Packagingmaterialsofyourmachineare
manufactured from recyclable materials.
Disposing of the old machine
Dispose of your old appliance in an
environmentally friendly manner.
•Youmayrefertoyourlocalagentor
solid waste collection center in your
municipality to learn how to dispose of
your machine.
Beforedisposingofyouroldmachine,cut
off the mains plug and make the door lock
unusable.
