LPG GAS INSTALLATION
“This appliance uses LPG (bottle) gas. The manufacturer and the seller do not
accept responsibility for any damage due to incorrect installation or gas
connection.”
• Soak the end of the plastic hose in hot water to soften it and then push the hose
end fully over the hose nozzle. (see sketch 1 below)
• Secure the hose by tightening the hose clamp. (See sketch 2 below)
• In a similar fashion, secure the other end of the hose to the regulator on the gas
bottle.
1 2
O Seal
Nozzle Hose
Clamp
CAUTION: Never use a naked flame to check for gas leaks
• Check for gas leaks after installation and whenever a new or re-filled gas bottle is
used for the first time.
• Ensure that the control knobs on the hob are in the OFF position.
• Open the valve on the Gas bottle.
• Using a small paint brush, apply some soapy water to all the connections.
• If there is a leak, bubbles will appear.
• If this happens, close the valve on the gas bottle.
• Check and tighten the connections immediately.
• Repeat the procedure to ensure that there are no further leaks.
LPG GAS HOB
Operating the gas burners
• To switch the burner on, push down slightly on the relevant control knob and then
turn it to the left (counter – clockwise). The large flame symbol on the knob
indicates the maximum and the small flame the lowest setting.
• Push the ignition button and hold it for approximately 10 seconds.
• There is no ignition button on the 5 burner model. Instead, push down
slightly on the relevant control knob, turn it to the maximum position and
hold it down for 10 seconds.
• The gas will then be lit automatically.
• Release the button 3 to 5 seconds after the flame is observed at the burner.
• If the flame fails to continue burning, please repeat the sequence.
• Adjust the flame according to need.
