Dehler 25 CR - Specific Systems and Components; Exhaust System Diagram; Rudder System Diagram

DEHLER 25Cr
27
Spirit stove
There is an manufactors manual of the
cooker. Therefore we make no advises
here.
ATTENTION
Please read the orginal manual of the
cooker.
Exhaust system
Figure 13 Exhaust system
1. Engine
2. Silencer
3. Exhaust pipe
4. Gooseneck
5. Exhaust
Rudder system
Figure 14 Rudder system
1. Tiller bracket
2. Fixing tiller
3. Upper bearing
4. Rudder reinforcement
5. Rudderblade
6. Upper rudder bracket
7. Tiller
8. Bridge
9. Fixing bolt for rudder
10. Lower bearing
11. Lower rudder bracket
