Hull skin fittings
1
2
3
4
5
6
7
8
9
Figure 17 Hull skin fittings
1. Skin fitting 1 _“ depth sounder
2. Skin fitting 1 _“ log
3. Skin fitting 3/4" sink outlet with quick-
acting ball valve
4. Skin fitting 1 1/4" outlet for toilet or
holding tank with quick-acting ball
valve
5. Skin fitting 3/4" hand basin outlet with
quick-acting valve
6. Skin fitting 3/4“ sea water inlet for toilet
with quick-acting ball valve
7. Skin fitting 3/8“ holding tank vent
8. Skin fitting 3/8“ sea water inlet for
engine
9. Skin fitting 2“ exhaust outlet
