5.2 Wiring diagram
N
L1
S21
S20
BL
BR
GR
Capacitor 5.0uF
(C)
215120
Fig. 12
BL: Blue/Neutral
BR: Brown/Phase
C: Capacitor 5.0 uF
GR: Green/GFCI
DeLaval swinging cow brush SCB3
Installation
© DeLaval 2016.
2016-07-19, Version 5 19 (26) 84948801
