Dell EMC Networking N Series User Manual

12
Console Port LEDs
System LEDs
The system LEDs, located on the front panel, provide information about the
power supplies, thermal conditions, and diagnostics.
Table 1-8 shows the System LED definitions for the Dell EMC Networking
N2200 switches.
Table 1-7. Console Port LED Definitions
LED Color Definition
Link/SPD LED Off There is no link.
Solid green A link is present.
Table 1-8. N2200-ON Series System LED Definitions
LED Color Definition
Status Solid green Normal operation.
Blinking green The switch is booting.
Solid amber Major fault. Displays summary of all major
faults within the switch.
Flashing amber Minor fault. Displays summary of all minor
faults within the switch.
Solid red A critical system error has occurred.
Blinking red A noncritical system error occurred (fan or
power supply failure).
Power Off There is no power or the switch has experienced
a power failure.
Solid green Power to the switch is on.
Solid amber POST in progress.
Flashing amber Power supply fault.
Fan Solid green The fan is powered and is operating at the
expected RPM.
Flashing amber A fan fault has occurred.
