Procedure C: Obtain customer verification
Perform this procedure if the three conditions listed below are true:
l
The customer-supplied PDU source cables are already plugged into the storage
bay PDU.
l
You have no access to the area below the raised floor.
l
The customer's electrician is not available at the installation site.
Procedure
1. Have the customer verify that their electrician has complied with power
specifications for voltage levels and redundancy. If the customer cannot verify
this, provide them with a copy of Procedure A. Inform the customer that their
array may prematurely shut down in the event of a site power issue.
2. Record the customer-supplied PDU information (AC source voltage) as
described in step 1 of Procedure A, Task 1: Customer's electrician on page 17
and label the PDUs as described in Applying PDU labels on page 25.
PDU labels
Before applying labels to the sidewalls of the cabinet, one of the following procedures
must have been completed:
l
Procedure A: Working with the customer's electrician onsite on page 16
l
Procedure B: Verify and connect on page 22
l
Procedure C: Obtain customer verification on page 23
If necessary, see Selecting the proper AC power connection procedure on page 15 to
select the correct procedure.
PDU label part number
Table 4
PDU label part number
Part Number Description
046-001-750 LABEL: CUSTOMER 1P 3P PDU INFO WRITEABLE
Table 5 PDU label location, Dell EMC racks
Product Location
PowerMax 2000 HERC OPEN ME FIRST KIT
PN 106-887-306
PowerMax 8000 OPEN ME FIRST FIELD INSTALL KIT
PN 106-887-026
Best Practices Guide for AC Power Connections
Procedure C: Obtain customer verification 23
