19" LCD Color Monitor Dell 1908FPC
17
Universal Serial Bus (USB) Interface
This monitor supports High-Speed Certified USB 2.0 interface.
USB ports:
• 1 upstream - rear
• 4 downstream - 2 on rear; 2 on left side
4.2 Factory Preset Display Modes
4.3 Power Supply Requirements
A/C Line voltage range : 100 V ~ 240 V
A/C Line frequency range
: 50 ± 3Hz, 60 ± 3Hz
Current : 1.5A max at 100V; 0.8A max at 240 V
Peak surge current : < 60A peak at 240 VAC and cold starting
Leakage current : < 3.5mA
Power line surge : No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
DC output Voltage
: 5VDC ± 5％; 13VDC± 10％,12VDC± 5％
Data Rate Power Consumption
High speed 480 Mbps 2.5W (Max., each port)
Full speed 12 Mbps 2.5W (Max., each port)
Low speed 1.5 Mbps 2.5W (Max., each port)
