Dell 1908FPC - 6 Mechanical Instructions

19" LCD Color Monitor Dell 1908FPC
25
6. Mechanical Instructions
Note: Firstly, put the monitor on a soft, flat and clean surface, wear gloves.
Item Fig Remark
Remove stand
1. Rotate the stand to allow
access to the stand
release button.
2. Press the Stand release
button and lift up the
Stand and away from the
monitor.
1. Remove the 4 screws
Remove rear
cover
2. Pry the monitor up then
find out the hooks’
position, use the tool (like
the picture or other card)
to insert into the gap of
bezel and rear cover.
