19" LCD Color Monitor Dell 1908FPC
89
R811 061G0805154 RST CHIPR 150KOHM +-5% 1/8W
R816 061G0805155 RST CHIPR 1.5 MOHM +-5% 1/8W
R808 061G1206474 470KOHM 1/8W
C803 065G0805103 32 10NF/50V/0805/X7R
C808 065G0805682 32 MLCC 0805 CAP 6800PF K 50V X7R
D802 093G 64 33 DIO SIG SM BAV99 (PHSE)R
D804 093G 64 33 DIO SIG SM BAV99 (PHSE)R
ZD801 093G 39GA01 T RLZ5.6B
Q11G0012 1 CLIP
Q41G780070088A PIG EMEA 1908FP
Q44G9003130 corner paper
SQ15G82714D Main Frame
Diversity Of T96AGHHKFDDFDC Compared With T96GGCHKFDDGDP
Location Part No. Description
089G 728LAA 2D SIGNAL CABLE
089G174EGAA 1 DVI CABLE
089G402A18NYHD POWER CORD
0M1G 130 5225 CR3 SCREW
E750L 750GLU90G2412D000D PANEL M190EG02 V40 DELL AUO
CBPC6AGCDGQ MAIN BOARD REV:A00,V5C03
C609 067G215Y2207NV KY50VB22M-CC3 5*11
PWPC1942AUD4P POWER BOARD REV:A00
R809 061G0805105 1MOHM 1/10W
R826 061G0805152 RST CHIPR 1.5 KOHM +-5% 1/8W
R811 061G0805154 RST CHIPR 150KOHM +-5% 1/8W
R816 061G0805155 RST CHIPR 1.5 MOHM +-5% 1/8W
R808 061G1206474 470KOHM 1/8W
C803 065G0805103 32 10NF/50V/0805/X7R
C808 065G0805682 32 MLCC 0805 CAP 6800PF K 50V X7R
D802 093G 64 33 DIO SIG SM BAV99 (PHSE)R
D804 093G 64 33 DIO SIG SM BAV99 (PHSE)R
ZD801 093G 39GA01 T RLZ5.6B
Q11G0012 1 CLIP
SQ15G82714D Main Frame
Diversity Of T96GGHHBFDDFDC Compared With T96GGCHKFDDGDP
Location Part No. Description
E750L 750GLG90E8L32D000D PANEL LM190E08-TLL3 NJ DELL LPL
CBPC7GGCDGQ MAIN BOARD REV:A00,V5C03
