Installation
UPS
Communication Bay
Input Terminal Block
USB Port
Eight IEC 320-C13 Receptacles
(Load Segment 1)
REPO Ports
RS-232 Port
Ground Screw
Two IEC 320-C19 Receptacles
(Load Segment 2)
EBM Connector
Output Circuit Breaker
Figure 5. 3750W, 230V Rear Panel
UPS
Communication Bay
Input Terminal Block
USB Port
Four IEC 320-C19 and
Two L6-20 Receptacles
(Load Segment 1)
REPO Ports
RS-232 Port
Ground Screw
One L6-30 Receptacles
(Load Segment 2)
EBM Connector
Output Circuit Breaker
Figure 6. 4200W, 208V Rear Panel
