Removing and Replacing Parts 4-5
Drives
Figure 4-4 shows an example of drive hardware that can be installed in the com-
puter. Refer to this figure when you perform any of the procedures in the
following subsections.
Figure 4-4. Drive Hardware
SCSI hard-disk
drive bay (6)
SCSI connector
(BACKPLANE SCSI1)
SCSI2 CD-ROM
drive
3.5-inch diskette drive
DC power cable
diskette/tape drive
interface cable
diskette drive interface
connector (FLOPPY)
SCSI interface
cable
SCSI backplane
board
system board
SCSI connector
(SCSI2 CD-ROM)
