Dell 4100 - Front Bezel

4-4 Dell PowerEdge 4100/180 and 4100/200 Systems Service Manual
Front Bezel
Figure 4-3. Front Bezel Removal
To remove the front bezel, follow these steps:
1. Remove the computer covers.
2. Release the two tabs on each side of the bezel.
3. Slide the front bezel toward the front of the computer.
tab (4)
front bezel
