Adjusting Image Shape
Projection
Distance
(m)
[A]
Min Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal
(inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.3 40.47"/102.79 cm 90 50 58 8
1.42 44"/111.76 cm 98 55 64 9
2.84 88"/223.52 cm 196 110 128 18
4.26 133"/337.82 cm 294 165 192 27
5.68 177"/449.58 cm 391 220 255 35
7.1 221"/561.34 cm 489 275 319 44
Projection
Distance
(m)
[A]
Max Zoom
Image size
Projector base to
top of image (cm)
[C]
Projector base to
bottom of image
(cm)
[D]
Diagonal (inch/cm)
[B]
Width (cm)
[W]
Height (cm)
[H]
1.3 55"/139.7 cm 122 68 79 11
1.42 60"/152.4 cm 133 75 87 12
2.84 120"/304.8 cm 266 150 174 24
4.26 180"/457.2 cm 399 224 260 36
5.68 240"/609.6 cm 532 299 347 48
7.1 300.3"/762.76 cm 665 374 434 60
* This graph is for user reference only.
* Offset Ratio: 116±5%
