Close Bin1 Door
The rear door of output expander is not
securely latched.
Close the door until it locks into place.
Close Fuser Door
The fuser door is not securely latched.
Open the rear door and close the fuser
door until it locks into place.
Tray [x] Open
Tray [x] Open
Close Tray [x]
The displayed tray is open.
Close the tray until it locks into place.
HCF Open
HCF Open
Close Door
HCF(High Capcity Feeder) is open.
Close the HCF until it locks into place.
Tray [x] Empty
Load [Size][Type]
There is no paper in the tray.
Load paper in the tray. See "Loading
Print Media in the Paper Tray".
HCF Empty
Load [Size][Type]
There is no paper in the HCF.
Load paper in the HCF. See "Using the
High Capacity Feeder".
MPF Empty
Load [Size][Type]
Press Select
There is no paper in the multi-purpose
feeder.
Load paper in the multi-purpose feeder.
See "Using the Multi-purpose Feeder".
Paper Mismatch/
Tray [x]/MPF
Load [Size][Type]
Continue ,
Cancel
The paper size specified in the printer
properties does not match the paper
being loading.
Load the correct paper in the tray.
Paper Jam 0
Check Toner Cover
Paper has jammed around the toner
cartridge area.
Clear the jam. See "Around the toner
cartridge".
MP Tray
Check MPF Door
Paper has jammed in the feeding area of
the multi-purpose feeder.
Clear the jam. See "Multi-purpose feeder
Jam".
Paper Jam 0
Check Tray[x]
Paper has jammed in the feeding area of
the paper tray.
Clear the jam. See "Paper Feed Jam (tray
1)" or "Paper Feed Jam (optional trays)".
Paper Jam 1
Open/Close Door
Paper has jammed in the paper exit area
or around the toner cartridge area.
Clear the jam. See "In the paper exit
area" or "Around the toner cartridge".
Paper Jam 2...
Paper has jammed in the paper exit area.
Clear the jam. See "In the paper exit
area" or "Around the toner cartridge".
Duplex jam 0...
Paper has jammed during duplex
printing.
Clear the jam. See "Duplex jam 0".
Duplex jam 1...
Paper has jammed during duplex
printing.
Clear the jam. See "Duplex jam 1".
Standard Bin Full/
Standard Bin is 90%
Full
The output tray is full.
The output tray can hold up to 250
sheets of plain paper. Once the paper is
removed from the output tray, the printer
resumes printing.
Optional Bin1 Full
The output tray of output expander is
full.
The output expander can hold up to 600
sheets of plain paper. Once the paper is
removed from the output expander, the
printer resumes printing.
Open Heat
Open Heat Error
Power Cycle
There is a problem in the fuser unit.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Low Heat/
Low heat Error
Power Cycle
There is a problem in the fuser unit.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Over Heat
Overheat Error
Power Cycle
There is a problem in the fuser unit.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
LSU Motor Error/
LSU Motor Error/
Power Cycle
A problem has occurred in the LSU(Laser
Scanning Unit).
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Hsync Error/
LSU Hsync Error
Power Cycle
A problem has occurred in the LSU(Laser
Scanning Unit).
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Fuser Error
Fuser Fan Locked
Power Cycle
There is a problem in the cooling fan of
the printer.
Open and then close the rear door.
SMPS Error
SMPS Fan Locked
Power Cycle
There is a problem in the SMPS fan of the
printer.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Fuser Error/
Fuser Not Installed
Check Rear Door
The fuser unit is not installed or not
detected.
Install the fuser unit or open and then
close the rear door.
Inner Temp. Error/
Inner Temp. Error
Power Cycle
There is a problem in your printer system.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Deve Motor Error/
Deve Motor Locked
Power Cycle
There is a problem in the development
motor of the printer.
Unplug the power cord and plug it back
in. If the problem persists, please call for
service.
Power Saver
The printer is in power save mode.
When data is received, it switches to on-
line automatically.
Warming Up
Your printer is warming up now.
Please wait a few minutes.
