Dell 5810 - Page 4

Page 4 of 15
Dave Pimm – Avid Technology – Dec 24th, 2014
Rev A
AVID qualified HBA info
AVID qualified HBA
AVID Part
Number
Slot Location
Function
Vendor qualified 3
rd
party
X8 PCI-E or lesser interface
Not stocked by
AVID
#1
¾ Length PCI
form factor or
smaller
Vendor qualified 3
rd
party hardware interface. See
release notes and Avid website for information
regarding supported 3
rd
party hardware
Avid HIB, DX Interface HBA **
Active: 7030-30048-02
Active: 7030-30048-01
Active: 7030-20084-01
#5
Avid DX Hardware Interface HBA
Atto R680
Not stocked by
AVID
#4
Local SAS Storage Support –
Avid VideoRAID ST (5-bay) Xtore
StudioRAID 5Ti (5-bay)
LSI 9200-8e SAS controller
7030-30036-01
#4
SAS Local Storage:
Xtore StudioRAID 16Re (16-bay) chassis
Xtore StudioRAID 5Te (5-bay) chassis
Intel PRO 1000 PT
7030-20139-01
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet Dual
Gb ISIS Connectivity
Intel i350-T2 – Dual Gb NIC
Not stocked by
AVID
#4
Shared Storage: Unity ISIS Copper Gb-Ethernet Dual
Gb ISIS Connectivity
Intel PRO 1000 PF - ISIS
Not stocked by
AVID
#4
Shared Storage: Unity ISIS Optical Gb-Ethernet
Myricom 10G-PCIE-8B-S
Myricom 10G-PCIE-8B2-2S
7030-30041-01
#4
Shared Storage: Unity ISIS 10Gb-Ethernet for Hi-
Res client (ISIS 5000 / 7000)
Red Rocket Accelerator
Not stocked by
AVID
#4
Accelerator for RED files
** Avid DX Interface HBA Support Note: (See reference pictures on page 7 of this guide).
All 3 versions of the DX interface HBA are supported on the 5810 with Media Composer / Symphony 8.x
1) Active DX interface HBA 7030-30048-01
2) Active DX interface HBA 7030-30048-02
3) Active DX interface HBA 7030-20084-01
