Page 5 of 15
Dave Pimm Avid Technology Dec 24th, 2014
Rev A
4.) Slot Configuration:
Slot Configuration Information
Slot #
Electrical
Mechanical
1
X8 PCI-E Gen 3
X16
Vendor
Qualified 3
rd
Party Hardware PCI-e Interface
requiring:
X8 PCI-E or lesser interface
¾ Length PCI form factor or smaller
2
x16 PCI-E Gen 3
(225Watts)
x16
Graphics Card:
Nvidia K2200
3
X1 PCI-E Gen 2
x1
Vendor
Qualified 3
rd
Party Hardware PCI-e Interface
requiring:
X1 PCI-E interface
4
x16 PCI-E Gen 3
x16
Local SAS Storage Controllers
Or
Shared Storage Controller
or
Pro Tools HD h/w
or
Red Rocket Accelerator
5
x4 PCI-E Gen 2
x16
Avid HIB, DX Interface HBA
7030-30048-01, 7030-30048-01 & 7030 20084-01
OR
Dell Thunderbolt Adapter
6
PCI 32bit /33MHz
PCI 32/33
Not used
Embedded Intel
I217-LM
Gb NIC
PCI-E x1
Gen 2
Qualified for Avid ISIS 5000 / 7000 connectivity.
5.) Use of embedded NIC ports for ISIS connectivity Important Information
The 5810 has one embedded NIC port that is qualified to run with Isis
