About Your Monitor | 19
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the
monitor.
Transfer Speed Data Rate Power Consumption*
Super-speed 5 Gbps 4.5 W (Max, each port)
High speed 480 Mbps 4.5 W (Max, each port)
Full speed 12 Mbps 4.5 W (Max, each port)
NOTE: This monitor is Super-Speed USB 3.0 compatible.
* Up to 2 A on USB downstream port (port with
lightning icon) with
BC1.2-compliant devices or normal USB devi
ces.
USB Upstream Connector
Pin
Number
9-pin Side of the
Connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
