Setting Up the Monitor | 27
Wall Mounting (Optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come wit
h the VESA-compatible wall mounting kit.
1. P
lace the monitor panel on a soft cloth or cushion on a stable, flat table.
2. Remove the
stand.
3. U
se a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. A
ttach the mounting bracket from the wall mounting kit to the monitor.
5. M
ount the monitor on the wall by following the instructions that comes with
the wall mounting kit.
NOTE: For use only with UL-listed wall mount bracket with minimum
weight/load bearing capacity of 14 kg.
