CHAPTER 3: CONNECTING DEVICES
Two types of audio connectors:
1
2
1 stereo jack - Your headpone
jack should have this type of
connector
2 mono jack - Your microphone
should have this type of
connector
Connecting External Speakers
Your Alienware notebook has three integrated audio out connectors and one
audio in connector. e audio out connectors deliver quality sound and support
5.1 surround audio. You can connect the audio input connector from a home stereo
or speaker system for a heightened gaming and media experience.
1
2
3 4
1 front speakers (left and right)
Audio Out connector/headphone
jack (Green)
3 rear surround (left and right)
Audio Out connector (Black)
2 center speaker and subwoofer
Audio Out connector/headphone
jack (Orange)
4 Audio In connector/
microphone jack
