CHAPTER 8: BASIC SPECIFICATIONS
Dimensions
Height 51.31 mm to 53.59 mm (2.02 inches to 2.11
inches) - Front to Back
Width 405.89 mm (15.98 inches)
Depth 321.31 mm (12.65 inches)
Weight
(with WUXGA LCD, single
NVIDIA graphics card, and
9-cell battery)
5.3 kg (11.68 lbs)
NOTE: e weight of your notebook will vary
depending on the conguration ordered and
the manufacturing variability.
Processor and System Chipset
Processor Intel
®
Quad-Core
Intel
®
Dual-Core
System Chipset NVIDIA
®
GeForce
®
9400M G
Memory
Connectors two internally-accessible DDR3 SODIMM
sockets
Capacities 2 GB to 8 GB
Memory types 1067 MHz, 1333 MHz
(dual channel congurations)
Memory congurations
possible
2 GB, 3 GB, 4 GB, 6 GB, and 8 GB
Ports and Connectors
IEEE 1394a 4-pin serial connector
Network adapter RJ-45 connector 10/100/1000
USB four 4-pin USB 2.0-compliant connectors
eSATA one 11-pin eSATA/USB combo connector
VGA 15-hole connector
HDMI 19-pin connector
DisplayPort 20-pin connector
AC Adapter
Output current -
240 W 12.31 A (continuous)
Rated output voltage 19.5 VDC
Communications
Network adapter 10/100/1000 Ethernet LAN on system board
Wireless
WLAN Mini-Card (Half Mini-Card slot)•
WPAN, Bluetooth card (full card slot)•
