Using advanced print features
114
4. Special features
Overlay
(Using a page overlay)
a Click the Advanced tab.
b Select the desired overlay from the Text drop-
down list.
c If the overlay file you want does not appear in
the Text drop-down list, select Edit... from the
list and click Load. Select the overlay file you
want to use.
If you have stored the overlay file you want to
use in an external source, you can also load the
file when you access the Open window.
After you select the file, click Open. The file
appears in the Overlay List box and is
available for printing. Select the overlay from
the Overlay List box.
d If necessary, check Confirm Page Overlay
When Printing box. If this box is checked, a
message window appears each time you
submit a document for printing, asking you to
confirm printing an overlay on your
document.
If this box is not checked and an overlay has
been selected, the overlay automatically
prints with your document.
e Click OK or Print until you exit the Print
window.
Item Description
Overlay
(Deleting a page overlay)
a In the Printing Preferences window, click the
Advanced tab.
b Select Edit in the Text drop down list.
c Select the overlay you want to delete from the
Overlay List box.
d Click Delete.
e When a confirming message window appears,
click Yes.
f Click OK or Print until you exit the Print
window. You can delete page overlays that
you no longer use.
a. This option is not available when you use XPS driver.
Item Description

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell B1260dn and is the answer not in the manual?

Dell B1260dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Resolution color600 x 600 DPI
Maximum resolution1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)28 ppm
Maximum duty cycle20000 pages per month
Number of print cartridges1
Page description languagesPCL 6, SPL
Memory typeDDR2
Processor modelARM 11
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity251 sheets
Maximum print size210 x 297 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper, Transparencies
Paper tray media weight60 - 163 g/m²
ISO A-series sizes (A0...A9)A4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supportedFedora 11, Fedora 12, Fedora 13, Fedora 14, Fedora 15, Fedora 6, Fedora 7, Fedora 8, Fedora 9, SuSE Linux 10, SuSE Linux 11, Ubuntu 10.04, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 9.10
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)- W
Display-
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)348 x 338 x 197 mm
