Glossary
143
Glossary
MAC address
Media Access Control (MAC) address is a unique identifier associated with a network
adapter. MAC address is a unique 48-bit identifier usually written as 12 hexadecimal
characters grouped in pairs (e. g., 00-00-0c-34-11-4e). This address is usually hard-
coded into a Network Interface Card (NIC) by its manufacturer, and used as an aid for
routers trying to locate machines on large networks.
MFP
Multi Function Peripheral (MFP) is an office machine that includes the following
functionality in one physical body, so as to have a printer, a copier, a fax, a scanner
and etc.
MH
Modified Huffman (MH) is a compression method for decreasing the amount of data
that needs to be transmitted between the fax machines to transfer the image
recommended by ITU-T T.4. MH is a codebook-based run-length encoding scheme
optimized to efficiently compress white space. As most faxes consist mostly of white
space, this minimizes the transmission time of most faxes.
MMR
Modified Modified READ (MMR) is a compression method recommended by ITU-T
T.6.
Modem
A device that modulates a carrier signal to encode digital information, and also
demodulates such a carrier signal to decode transmitted information.
MR
Modified Read (MR) is a compression method recommended by ITU-T T.4. MR
encodes the first scanned line using MH. The next line is compared to the first, the
differences determined, and then the differences are encoded and transmitted.
NetWare
A network operating system developed by Novell, Inc. It initially used cooperative
multitasking to run various services on a PC, and the network protocols were based
on the archetypal Xerox XNS stack. Today NetWare supports TCP/IP as well as IPX/
SPX.
OPC
Organic Photo Conductor (OPC) is a mechanism that makes a virtual image for print
using a laser beam emitted from a laser printer, and it is usually green or rust colored
and has a cylinder shape.
An imaging unit containing a drum slowly wears the drum surface by its usage in the
printer, and it should be replaced appropriately since it gets worn from contact with
the cartridge development brush, cleaning mechanism, and paper.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell B1260dn and is the answer not in the manual?

Dell B1260dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Resolution color600 x 600 DPI
Maximum resolution1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)28 ppm
Maximum duty cycle20000 pages per month
Number of print cartridges1
Page description languagesPCL 6, SPL
Memory typeDDR2
Processor modelARM 11
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity251 sheets
Maximum print size210 x 297 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper, Transparencies
Paper tray media weight60 - 163 g/m²
ISO A-series sizes (A0...A9)A4
Multi-Purpose Tray media weight60 - 220 g/m²
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supportedFedora 11, Fedora 12, Fedora 13, Fedora 14, Fedora 15, Fedora 6, Fedora 7, Fedora 8, Fedora 9, SuSE Linux 10, SuSE Linux 11, Ubuntu 10.04, Ubuntu 8.04, Ubuntu 8.10, Ubuntu 9.04, Ubuntu 9.10
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)- W
Display-
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)348 x 338 x 197 mm
