Operating the monitor | 89
The following are illustrations of several connection scenarios and their USB Selection
menu settings, as illustrated in corresponding color frames.
1. When connecting HDMI + USB-B to computer 1 and DP + USB A to C to
computer 2:
HDMI
DP
USB A to C
1
1
3
2
2
4
4
USB-B
3
NOTE: The USB Type-C connection currently supports only data transfer.
Ensure USB Selection for HDMI is set to USB-B and DP is set to USB-C
90
W.
Exit
24/27/34 Monitor
Input Source
Color
Brightness/Contrast
Display
PIP/PBP
Personalize
Others
Menu
USB
Audio
DP assign to USB-B
HDMI assign to
USB-B
