About Your Monitor 19
RS232 connector
RS232 Monitor Pin Assignment (Facing Monitor)
RS232 Serial Communication Cable Pin Assignment (Facing Cable)
Pin Assignments
RS232 PIN DESCRIPTION RS232
1
2 TXD 2
3 RXD 3
4
5 GROUND 5
6
7 Not Used 7
8 Not Used 8
9
