Dell C5517H - Resolution and Video Specifications

22  About Your Monitor
Resolution Specifications
Model number Dell C5517H monitor
Horizontal Scan range 30 kHz to 83 kHz (automatic)
Vertical Scan range 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1920 x 1080 at 60 Hz
Support Video Mode
Model number Dell C5517H monitor
Video display capability
(HDMI&DP playback)
480p, 576p, 720p, 1080p, 1080i
Electrical Specifications
Model number Dell C5517H monitor
Video input signals Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input impedance
Digital HDMI: 600 mV for each dierential line, 100 ohm
input impedance
Digital DisplayPort
Maximum Output dierential Voltage Level 1.38V,
100ohm input impedance
Synchronization input
signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on green)
AC input voltage /
frequency / current
100 VAC to 240 VAC/50 Hz or 60 Hz +/- 3 Hz/2.5 A
(Max.)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
