About Your Monitor 21
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the monitor.
NOTE : This monitor is Super-Speed USB 3.0 compatible.
Transfer Speed Data Rate Power Consumption
Super-Speed 5 Gbps 4.5W (Max, each port)
High Speed 480 Mbps 4.5W (Max, each port)
Full Speed 12 Mbps 4.5W (Max, each port)
USB Upstream Connector
Pin Number 9-pin Side of the Connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
